Diodes
Showing all 9 results
-
Fast Recovery Diode
1N5819
The 1N5819 is a Schottky diode known for its fast recovery time and low forward voltage drop characteristics. It belongs to the family of semiconductor devices designed to provide efficient rectification and voltage clamping in various electronic circuits.
Datasheet
SKU: n/a -
Fast Recovery Diode
FR-104
The FR104 diode is a fast switching diode, with a continuous reverse voltage rating of 400V and is suitable for forward currents of up to 1A, the reverse recovery time is 150ns. The FR104 diode is ideal for use in linear and switched voltage converter circuits.
Datasheet
SKU: n/a -
Diodes
70UP20
The “70UP20” is a diode often used in high-power applications such as welding machines. This type of diode is typically characterized by its ability to handle high reverse voltages and significant forward current, making it suitable for the demanding environments of welding equipment where rectification of high AC voltages to DC is required.
Datasheet
SKU: n/a -
SMD Diodes
SS-16
The SS series represents a highly efficient, low power loss general-purpose Schottky rectifier. Its clip-bonded leg structure offers excellent thermal performance and minimal electrical resistance. This rectifier is ideally suited for applications such as freewheeling, secondary rectification, and reverse polarity protection.
Features
• Low profile package
• Ideal for automated placement
• Guardring for overvoltage protection
• Low power losses, high efficiency
• Low forward voltage drop
• High surge capability
• Meets MSL level 1, per J-STD-020,LF maximum peak of 260 °C
• AEC-Q101 qualified available- Automotive ordering code: base P/NHE3 or P/NHM3Applications
● Low Voltage● High-Frequency Inverters● Free Wheeling● Polarity ProtectionDatasheet
SKU: n/a -
SMD Diodes
SS-14
The SS series represents a highly efficient, low power loss general-purpose Schottky rectifier. Its clip-bonded leg structure offers excellent thermal performance and minimal electrical resistance. This rectifier is ideally suited for applications such as freewheeling, secondary rectification, and reverse polarity protection.
Features
• Low profile package
• Ideal for automated placement
• Guardring for overvoltage protection
• Low power losses, high efficiency
• Low forward voltage drop
• High surge capability
• Meets MSL level 1, per J-STD-020,LF maximum peak of 260 °C
• AEC-Q101 qualified available- Automotive ordering code: base P/NHE3 or P/NHM3Applications
● Low Voltage● High-Frequency Inverters● Free Wheeling● Polarity ProtectionDatasheet
SKU: n/a
